| Model | RZ16E |
|
Working Height Maximum |
16m |
|
Platform Height Maximum |
14m |
|
Lift capacity |
230kg |
|
Horizontal outreach maximum |
7.8m |
|
up&over clearance maximu |
7.7m |
|
Platform dimensions |
1.53mx0.76 |
|
Length(stowed) |
6.34m |
|
Width(stowed) |
1.75m |
|
Height(stowed) |
2.06m |
|
wheelbase |
2m |
|
Ground clearance-center |
0.2m |
|
platform rotation |
180° |
|
Turntable rotation |
355° |
|
Travel speed(stowed) |
5 km/h |
|
Travel speed(raised) |
0.8km/h |
|
Grade-ability |
30% |
|
Turning radius （minimun） |
3.8m |
|
drive & steer mode |
4x2x2 |
|
Tire type |
250/15 |
|
Battery |
48/390V/AH |
|
Charger |
48/60 V/A |
|
Control voltage |
12V |
|
weight |
6800kg |
|
Hydraulic oil tank capacity |
30L |
