| Model | RL16 |
|
Working Height Maximum |
16 m |
|
Platform Height Maximum |
14 m |
|
Horizontal outreach maximum |
12.6 m |
|
Lift capacity |
300kg |
|
length(stowed) |
8.55 m |
|
Width(stowed) |
2.28 m |
|
Height(stowed) |
2.63 m |
|
wheelbase |
2.4 m |
|
Ground clearance-center |
0.43 m |
|
Platform measurement |
1.83m*0.76m |
|
Turing radius(inside) |
1.87 m |
|
Turing radius(outside) |
4.9 m |
|
Travel speed(stowed) |
4.4km/h |
|
Travel speed(raised) |
0.8km/h |
|
Grade-ability |
45% |
|
Tire type |
33x12-20 |
|
Turntable rotation speed |
0~0.8 rpm |
|
Turntable rotation |
360° continuous |
|
Platform leveling |
auto leveling |
|
Platform rotation |
±90° |
|
Fuel tank capacity |
151 L |
|
weight |
7,500 kg |
|
Control voltage |
12 V |
|
Drive & steering type |
4x4x2 |
|
Engine |
Kubotai/ Yanmar |
|
Engine power |
36kw/2600rpm |
